Product description details / Product description
* 200 million pixels HD CMOS，18 times photics zooming,4 times electron zooming
* Provide from NTSC/PAL to 1080p30 format video of the entire HD output format.
* Equipped with new type of DC motor, to make it quiet, quickly, wide range.
* RS485/422、R-232C long-range control port（VISCA、PELCO-D/PELCO-P protocol）
* Automatism plus、automatism focus, automatism white balance, low illuminance
* Level 360°round without cease, apeak 90°round with the speed reach at 120°/s
* 180°automatism overturn
* Horizontal view angle: 55.2°
* Provide from NTSC/PAL to 1080p30 format video of the entire HD output format.
* Equipped with new type of DC motor, to make it quiet, quickly, wide range.
* RS485/422、R-232C long-range control port（VISCA、PELCO-D/PELCO-P protocol）
* Automatism plus、automatism focus, automatism white balance, low illuminance
* Level 360°round without cease, apeak 90°round with the speed reach at 120°/s
* 180°automatism overturn
* Horizontal view angle: 55.2°
| 项 目Item | 技 术 指 标Specification |
| 摄像元件 Image sensor | 1/2.7英寸HD CMOS成像芯片，200万像素，200 million pixels |
| 视频制式Video output | HD:1080p30，1080i/59.94，1080i/50，720p/59.94，720p/50SD:NTSC，PAL |
| 电子快门Electronic shutter | 1/2 To1/10000s |
| 最低照度Minimum illumination | 12Lx（50IRE，F1.6) |
| 水平视角Horizontal View Angle | 最大水平视角55.2°(Max wide) |
| 变焦倍数Zoom | 18倍光学变焦，4倍数字变焦，18X Optical zoom，4X Digital zoom |
| 信噪比(S/N) | ≥50dB |
| 同步方式Method of synchronization | 内同步（Sync） |
| 背光补偿 BLC | OFF/ON 自动背光补偿 Automatic backlight compensation |
| 视频输出幅度VAD | 1.0±0.2Vp-p，75Ω复合视频信号 |
| 旋转速度Rotational speed | 水平 level speed（0.1°～200°/秒）垂直 vertical speed（0.1°～150°/秒） |
| 转动范围Rotating range | 水平 level ±150°，垂直 vertical -30～90° |
| 预置点Preset | 128个 |
| 视频输出接口Video output interface | SDI接口（高清）、DVI-I接口（高清，可转为DVI-D、HDMI、YPbPr和VGA接口等）、BNC接口（标清） |
| 控制协议Control protocol | PELCO-D、PELCO-P、VISCA |
| 控制接口Control Interface | RS485/422、RS232 |
| 通信波特率Communication baud rate | 1200/2400/4800/9600/19200 bps |
| 地址范围Address Range | 0～255 |
| 温度 Temperature | 工作温度Work Temperature：0℃～+50℃存储温度 Storage Temperature：-20℃～+70℃ |
| 环境湿度Ambient humidity | 0～95%（无冷凝 No condensation） |
| 电源Power | 12V DC |
| 耗电量 Power consumption | <10W |
| 尺寸Size | L 260×W 160×H 140 mm (长X宽X高) |
